Acid & Hydrochloric Acid Dosing

How the System Works

Acid dosing is the standard way to correct high alkalinity and pH in cooling, process and wastewater streams. Because strong acids are hazardous, the system uses PVDF/PTFE wetted parts, a bunded and ventilated enclosure and leak detection, while a pH analyser trims the dose for stable, safe control without manual handling.

Standard Configuration

Bunded PP/PVDF day tank with level switch
Metering pump, PVDF/PTFE head, manual + automatic stroke
Online pH analyser with feedback control
Bunded, ventilated cabinet with leak detection
PLC control cabinet with touchscreen HMI

Key Features

Closed-loop pH control avoids acid overdose
Fully corrosion-resistant wetted parts
Bund, ventilation and leak alarm for safety
Neutralisation backup for spill protection
Remote alarm and data logging

Typical Applications

Cooling and process-water pH correction
Wastewater neutralisation
Desalination and demineralisation
Chemical process pH control
Swimming-pool and leisure-water balancing

Technical Specifications

Model	Tank material	Control mode	Power supply
ELT-AC200 / ELT-AC500	PP / PVDF	Manual / Automatic / PLC touchscreen	220V / 380V, 50Hz
ELT-AC1000 / ELT-AC2000	PP / PVDF + SS frame	PLC touchscreen / DCS / GPRS	380V, 50Hz
ELT-AC4000	PVDF (acid duty)	PLC with frequency inverter	380V, 50Hz

Our acid and hydrochloric acid dosing systems lower and stabilise pH in water and process streams using corrosion-proof pumps and leak-safe enclosures.
Each unit is engineered in 3D and can be supplied with PLC automation and touchscreen HMI control, ready to run from day one.
