How the System Works
Additive injection keeps a process stream within specification by continuously introducing small, precise amounts of catalyst, inhibitor or treatment chemical. A skid-mounted system provides a safe, calibrated injection point with back-pressure and check valves, protecting both the pump and the pipeline while holding tight dose accuracy.
Standard Configuration
- PE/PP/SS additive day tanks with level switches
- Diaphragm or plunger metering / injection pumps
- Back-pressure and check valves at injection point
- Flow, pressure and level transmitters
- PLC control cabinet with touchscreen HMI
Key Features
- High-accuracy, pulse-free injection
- Leak-safe with back-pressure protection
- Flow-proportional or analyser-trimmed dose
- Chemical-resistant wetted parts
- 4-20 mA / Modbus link to plant DCS
Typical Applications
- Pipeline and gathering-system injection
- Refinery and petrochemical additive dosing
- Polymer and catalyst addition
- Fuel and lubricant additive injection
- Water and process treatment injection
Technical Specifications
| Model | Frame material | Control mode | Power supply |
|---|---|---|---|
| ELT-AI100 / ELT-AI300 | Painted carbon steel | Manual / Automatic / PLC touchscreen | 220V / 380V, 50Hz |
| ELT-AI600 / ELT-AI1200 | Galvanised / SS frame | PLC touchscreen / DCS / GPRS | 380V, 50Hz |
| ELT-AI2000 | 304 SS frame | PLC with frequency inverter | 380V, 50Hz |
Our additive injection systems meter catalysts, inhibitors and process additives into flowing streams with high accuracy and no leakage.
Each skid is engineered in 3D and can be supplied with PLC automation and touchscreen HMI control, ready to run from day one.
Each skid is engineered in 3D and can be supplied with PLC automation and touchscreen HMI control, ready to run from day one.
Equipment Video
Typical Additive Injection System Components
1. Additive day tanks (PE/PP/SS)
2. Metering / injection pumps (diaphragm or plunger)
3. Back-pressure and check valves at injection point
4. Flow, pressure and level instrumentation
5. Control cabinet (PLC automatic control) and field instruments
Our Engineering Advantages
- Every system designed in the latest 2D and 3D CAD and SolidWorks software
- Automation and control available (PLC and HMI)
- One-stop, turnkey system supply
- Complete technical documentation
- Operator training and commissioning support
- Minimal on-site installation work
- Shorter lead times, lower project cost and a higher project success rate
